PCB Manufacturing: CNC Operations Jobs
To ensure the functioning of the finished product, the printed circuit board (PCB) manufacturing process necessitates a lengthy procedure. Regardless of whether a circuit board is single, double, or multilayered, the fabrication procedures employed only differ after the first layer is completed. Some PCBs may take 20 or more steps during fabrication due to changes in construction.
The complexity of printed circuit boards is proportional to the number of steps necessary to create them. Any step that is skipped or the method is shortened may have a detrimental impact on the circuit board’s performance. However, once constructed, the PCBs should function properly as critical electronic components.
Inner Layer and Pressing Operator
Minimum Ideally, an ITI graduate. Inner Layer and Pressing Operator certified training (course aligned to ELE/Q2101 published by the Electronics Sector Skills Council of India)
Skills required
PCB Manufacturing Job Description- Inner Layer and Pressing Operator
The following are the responsibilities of an Inner Layer and Pressing Operator:
- Cutting the panels to the desired dimensions
- Creating the PCB panel's inner layer
- Using an oxide coating
- By pressing the inner and outer layers together, the inner layer is laminated to the outer layer.
- Preventative maintenance of the machine
- Increasing productivity and maintaining high quality standards
Key competencies- Inner Layer and Pressing Operator
- Cutting, shaping, laminating, and pressing machine operating expertise
- Exceptional at validating the safety procedures to be performed when operating machinery.
- Understanding of how computers work and how to load programmes
- Familiar with machine flaws and their solutions, as well as the causes of these flaws
- IPC requirements for printed circuit boards knowledge
- Basic electronics knowledge
Salary- Inner Layer and Pressing Operator
Experience-wise | Salary |
For freshers | INR 8,000 to INR 9,000 per month |
For candidates with 1/2 years experience | INR 15,000 to INR 17,000 per month |
For candidates with 2+ years experience | INR 20,000 to INR 22,000 per month |
Top recruiting sectors- Inner Layer and Pressing Operator
PCB Industry in India
- India's PCB market has grown by 27%, and sales are predicted to reach Rs 9000 billion by 2016, which is significantly greater than most other countries.
- India, according to PCB players, needs to leapfrog and advance generations in terms of technology.
- According to research by the Indian Printed Circuit Association (IPCA), demand for PCBs has grown at a 35 percent annual rate in India. The local PCB sector not only serves the home market, but it also exports around a quarter of what it produces each year. 2 The expansion of the Indian PCB sector bodes well for job openings in this field, such as Inner Layer and Pressing Operator.
Drilling Operator
Minimum Ideally, an ITI graduate. Inner Layer and Pressing Operator certified training (course aligned to ELE/Q2101 published by the Electronics Sector Skills Council of India)
Skills required
- Lifting large weights is a must-have skill.
- Ability to operate in a standing position for lengthy periods of time
- Dexterity and stability in the hands
- Independent working ability
- Optical clarity
- Result-oriented
- Pay close attention to the details.
- Learner who is self-directed
- Participant in a group
- resolving issues
PCB Manufacturing Job Description- Drilling Operator
A Drilling Operator’s responsibilities include the following:
Key competencies- Drilling Operator
- Basic electronics and circuit design layout knowledge are required.
- familiarity with the operation and functioning of CNC machines
- Drilling fundamentals and micro-drilling knowledge Drilling techniques and drill tools knowledge
- The ability to use zero-defect drilling procedures
- Expertise in the use of machines and tools
- Skilled in maintaining ESD, dust-free, and 5S standards in accordance with business policy Knowledge of how to keep a safe and healthy work environment
- Working with dangerous materials is second nature to you.
- For electronic component safety, understanding electrostatic discharge (ESD) procedures is essential.
- IPC requirements for printed circuit boards knowledge
- Knowledge of how to properly dispose of hazardous substances, tools, and materials while according to environmental regulations
Salary- Drilling Operator
Experience-wise | Salary |
For freshers | INR 8,000 to INR 10,000 per month |
For candidates with experience | INR 12,500 to INR 16,000 per month |
Top recruiting sectors- Drilling Operator
Size of the Indian PCB Market
Except for motherboards, mobile phones, and high-end telecom equipment, PCB makers in India cater to a wide range of electronics applications. Consumer, industrial, and automotive electronics, as well as power and telecommunications, are the primary markets for PCBs.
India’s PCB market grew by 27% in 2014, and revenue is estimated to reach Rs 9000 billion by 2016, far above that of most other countries
HR Requirement Estimates
According to the IMaCS Analysis, the need for human resources in the Electronics Components industry is expected to rise from 1,49,000 in 2008 to 8,34,000 in 2022, a 6.85 million increase.
PCB Assembly is one of the top 14 sub-sectors with a significant employment potential, according to India’s Electronics Sector Skills Council. All of these variables combined indicate that career prospects for a PCB Drilling Operator are increasing.
Routing Operator
Minimum ITI Graduates are preferred. Routing Operator certification (course related to the Electronics Sector Skills Council of India’s ELE/Q2103 standard)
Skills required
PCB Manufacturing Job Description- Routing Operator
A Routing Operator’s responsibilities include the following:
Key competencies- Routing Operator
- Basic electronics and component knowledge
- Well-versed in loading CNC machine programmes Adept at using instruments such as table saws, routers, lathes, mills, and so on
- Understanding of CNC machining fundamentals and the G-code programming language
- Hand breaking, pizza cutter, V-cut, punch, router, sawing, laser and other de-paneling, cutting techniques Proficiency in basic geometry and the Cartesian coordinate system Well-versed in basic geometry and the Cartesian coordinate system
- Tooling for production routing is something I'm very familiar with.
- Understanding of how to utilise common hand tools to do machine and tooling repair
- Machine cooling and maintenance require knowledge of dangerous coolants and lubricants.
- Machine flaws and their causes are well-understood.
- IPC requirements for printed circuit boards are well-understood.
Salary- Routing Operator
Experience-wise | Salary |
For freshers | INR 7,000 to INR 8,000 per month |
For candidates with 1/2 years experience | INR 16,000 to INR 17,000 per month |
For candidates with 2+ years experience | INR 23,000 to INR 24,000 per month |
Top recruiting sectors- Routing Operator
Electronic System Design and Manufacturing (ESDM) Sector Opportunities and Challenges
The electronics business is fast expanding and is predicted to reach $400 billion in the United States by 2020.
India’s electronic sector grew at a CAGR of 16.4 percent from US $ 20 billion in 2008-09 to US $ 25 billion in 2012-13.
Consumer Electronics, IT Hardware, Telecommunications Equipment, Electronics Components, Strategic Electronics, Automotive, Medical, and Industrial Electronics are the eight verticals in the Indian ESDM sector. By 2022, the number of people employed in the sector is predicted to reach over 28 million.
